PCB Assembly

PCB Assembly
Availability:

PCB Assembly


Summary


One-station

manufacturing

solutions


·One-stop service in manufacturing.

·Abundant product lines to meet any needs.

·Real-time tracking of manufacturing progress.

·Professional DFM technical support.

·Focus on the production line to cost control.


Development to MP, Single panel to HDI boards, Industrial equipment to consumer electronics,

According to a variety of different needs, we can provide you with the best solutions and service.


Fabrication



Capability


Layer count

2 to 40L



Drilling
Hole to hole accuracy

±0.075mm
±0.003i



PTH Tolerance

±0.05mm

Maximum
Panel size

533×610mm

21i×24i

NPTH Tolerance

±0.076/-0mm
±0.003i/-0i

Minimum Board
thickness

0.60mm
0.024i

Routing
Edge to Edge accuracy

±0.10mm
±0.004i

Min.drill size

0.20mm
0.0078i

Maximum Board thickess

2.4mm
0.0945i

Aspect Ratio

6:1

Stamping
Edge to Edge accuracy

±0.076mm
±0.003i

Minimum core thickness(I/L)

0.75mm
0.003i

Trace width tolerance(≥4mils)

±20%

Minimum Cu thickness(Base)

1/3 oz
12um

Minimum trace width

0.076mm
0.003i

Vee-cut
Edge to Edge accuracy

±0.127mm
±0.005i

Maximum Cu thickness(Base)

2.0 oz
70um

Registration(O/L)

±0.076mm
±0.003i

√ 1pcs OK   √ Meddle-small lot   √ BVH/IVH   √ Special material   √ Rigid and flexible   √ Halogen-free   √ Expedited



Products

PCB



Assembly



Capability

Min. chip: 0201 (0603), 0402 (1005)

Min. spacing: BGA 0.4mm Pitch, QFP/QFP 0.3mm Pitch

Max. size: 533×610mm

Support type: Manual welding, DIP plug-in, SMT, Cable making, BGA ball, Rework, Connector crimping

Support product: Communications, Industrial control, Chip testing, Automotive electronics, Medical equipment,etc.

Support mode: Processing, Feed processing, Bonded processing, Processing of non-bonded

√ Japan imported equipment √ Two decades of experience √ Focus on prototyping √ Real-time progress tracking


Production line


SMT DIP assembly soldering.pdf


With over 30 years' experience in manufacturing and marketing quality pcb assembly to all over the world, Jinpei Electronics is recognized as one of the leading manufacturers and suppliers. We now have quantity of quality pcb assembly for sale, you can rest assured to buy it with our company at a competitive price.
