FEATURES ●Use non over case stacked technic. Small size. ●Stable performance. Good temperature and voltage characteristic. Time reliability and showerproof. ●High reliability ●Non-piezoelectric effect, non-polar,non-nonlinear distortion ●Low ESR, Low Noise Level ●Strong ability of anti-Pulse |
SPECIFICATIONS
Standard:IEC60384-20
Enviroment:55/125/56
Rated temperature:105℃
Temperature:55℃~125℃(+105℃ to + 125℃:decreasing factor 1.25% per℃ for V R(DC)
Rated Voltage:16V,50V
Capacitance:0.0033μF~0.1μF
Tolerance:G±2%,±5%(J), ±10%(K),
Voltage:1.50UR(5s)
DF:0.004(1KHz)
Insulation Resistance:≥3000MΩ
UR=16V, | 10V |
UR=50V, | 50V(20℃,1min) |
Welding process:Reflow soldering recommended
SMD Metallized PPS Film Capacitors SF2.pdf
With over 30 years' experience in manufacturing and marketing quality smd metallized pps film capacitors sf2 to all over the world, Jinpei Electronics is recognized as one of the leading manufacturers and suppliers. We now have quantity of quality smd metallized pps film capacitors sf2 for sale, you can rest assured to buy it with our company at a competitive price.
