Metallized Polypropylene Film Capacitors CL21

FEATURES ● Metallized polyester film, non-inductive wound construction ● Wide capacitance range, small size and light weight ● Long life due to self-healing effect ● Flame retardation epoxy resin powder coated

SPECIFICATIONS

Reference Standard：GB/T 7332 (IEC 60384-2)

Climatic Category ：55/105/21

Rated temperature：85℃

Operating temperature range： -55℃~105℃(+85℃ to +105

decreasing factor 1.25% per ℃ for VR(dc)

Rated Voltage：50/63V, 100V, 250V, 400V, 630V

Capacitance Range：0.010μF ~ 10.0Μf

Capacitance Tolerance：±5%(J), ±10%(K), ±20%(M)

Voltage Proof：1.6UR (5s)

Dissipation Factor：≤1.0% (20℃,1kHz)

Metallized Polypropylene Film Capacitors CL21.pdf

With over 30 years' experience in manufacturing and marketing quality metallized polyprorylene film capacitors cl21 to all over the world, Jinpei Electronics is recognized as one of the leading manufacturers and suppliers. We now have quantity of quality metallized polyprorylene film capacitors cl21 for sale, you can rest assured to buy it with our company at a competitive price.
