Rated Voltage:250Vac Rated Frequency:50/60Hz Rated Capacitance:3μF to 60μF Capacitance tolerance:+/-10% or +/-5% (upon request.) Rated Min.&Max. Temperatures:-40~+85 degrees Climatic category:40/85/21 Protection Degree:P0 Dissipation Factor:less than 0.002 at 50Hz,20 degrees Test Voltage between terminals:2Un,60sec Test Voltage between terminals and case:2KV,60sec Reference Standard:EN61048,EN61049 Case type:Plastic case Terminals:4-way quick connector Fixing: M8 metal stud |
ADVANTAGES
Very small dissipation factor, small volume, light weight, small inherent temperature rise, excellent self-healing stability, safety and high reliability. It is safe because the capacitor is installed with discharge resistor and temperature fuze.
APPLICATIONS
Power factor correction of transformers and magnetic ballasts in discharge lamps like fluorescent lamps, high pressure sodium vapor lamps,high pressure mercury vapor lamps, and metal halide lamps,etc.
Plastic Lighting Capacitors CBB80.pdf
With over 30 years' experience in manufacturing and marketing quality plastic lighting capacitors cbb80 to all over the world, Jinpei Electronics is recognized as one of the leading manufacturers and suppliers. We now have quantity of quality plastic lighting capacitors cbb80 for sale, you can rest assured to buy it with our company at a competitive price.
Rated Voltage:250Vac Rated Frequency:50/60Hz Rated Capacitance:3μF to 60μF Capacitance tolerance:+/-10% or +/-5% (upon request.) Rated Min.&Max. Temperatures:-40~+85 degrees Climatic category:40/85/21 Protection Degree:P0 Dissipation Factor:less than 0.002 at 50Hz,20 degrees Test Voltage between terminals:2Un,60sec Test Voltage between terminals and case:2KV,60sec Reference Standard:EN61048,EN61049 Case type:Plastic case Terminals:4-way quick connector Fixing: M8 metal stud |
ADVANTAGES
Very small dissipation factor, small volume, light weight, small inherent temperature rise, excellent self-healing stability, safety and high reliability. It is safe because the capacitor is installed with discharge resistor and temperature fuze.
APPLICATIONS
Power factor correction of transformers and magnetic ballasts in discharge lamps like fluorescent lamps, high pressure sodium vapor lamps,high pressure mercury vapor lamps, and metal halide lamps,etc.
Plastic Lighting Capacitors CBB80.pdf
With over 30 years' experience in manufacturing and marketing quality plastic lighting capacitors cbb80 to all over the world, Jinpei Electronics is recognized as one of the leading manufacturers and suppliers. We now have quantity of quality plastic lighting capacitors cbb80 for sale, you can rest assured to buy it with our company at a competitive price.
