FEATURES ●Metalized Polypropylene film, non-inductive type, axial ● Excellent self-healing property ● Wrapped with polyester adhesive tape and ends filled with Flame retardant epoxy resin |
SPECIFICATIONS
Reference Standard:GB/T10190 (IEC 60384-16)
Climatic Category :40/105/21
Rated temperature: 85℃
Rated Voltage:100V,160V,250V,400V,630V,800V,1000V,1250V
Capacitance Range:0.001μF ~ 15μF
Capacitance Tolerance:±5%(J), ±10%(K), ±20%(M)
Voltage Proof:1.6UR (5s)
Dissipation Factor:≤10×10-4(1kHz, 20℃)
TYPICAL APPLICATIONS
●Temperature compensation circuits
●Time, oscillator circuits
●Power factor correction and coupling capacitor in SMPS applications
Axial Metallized Polypropylene Film Capacitors CBB20.pdf
With over 30 years' experience in manufacturing and marketing quality axial metallized polypropylene film capacitors cbb20 to all over the world, Jinpei Electronics is recognized as one of the leading manufacturers and suppliers. We now have quantity of quality axial metallized polypropylene film capacitors cbb20 for sale, you can rest assured to buy it with our company at a competitive price.
