Screw Terminal Aluminum Electrolytic Capacitors CD139
Operating Temperature Range(℃):-40~+85 Rated Voltage Range(V) :350~450 Nominal Capacitance Range(µF):1000~18000 Capacitance Tolerance(20℃,120Hz):±20% |
Leakage Current(μA)
After 5 minutes at 20℃ application of rated voltage, leakage current is not more than 0.01CV or 1.5mA,whichever is smaller.
C: Nominal Capacitance(μF) V: Rated Voltage(V)
Dissipation Factor(20℃,120Hz)(tanδ):Less than 0.15
Load Life
After applying rated voltage with specified ripple current for 5000 hours at +105℃ and then resumed16 hours
Capacitance Change:±20% Initial measured value
Leakage Current: Not more than Initial specified value
Dissipation Factor: Not more than 200% Initial specified value
Shelf life
After storage for 1000 hours at +105℃,UR to be applied for 30 minutes and then resumed 16 hours
Capacitance Change:±20% Initial measured value
Leakage Current: Not more than Initial specified value
Dissipation Factor: Not more than 200% Initial specified value
With over 30 years' experience in manufacturing and marketing quality screw terminal aluminium electrolytic capacitors cd139 to all over the world, Jinpei Electronics is recognized as one of the leading manufacturers and suppliers. We now have quantity of quality screw terminal aluminium electrolytic capacitors cd139 for sale, you can rest assured to buy it with our company at a competitive price.
